Magnetic Field Tester TY2100 Rotating Platform, Adjustable Stroke, Wide Range of Applications - high-Precision 4-axis Measurement System for Permanent Magnets, Motors and More

TY2100 surface magnetic field automatic test system TY2100 is a special device for automatically measuring the magnetic field distribution of permanent magnet materials and motor rotor surfaces. It can automatically scan specimens surfaces in three dimensions and calculate the surface magnetic field distribution. feature Tesla instrument: Measuring range: 0~2000mT, minimum resolution: 10μT, measurement uncertainty: 0.5%. Rotating test platform: The test platform is equipped with a rotating chuck, which is driven by a precision stepper motor to drive the sample under test in the W-axis direction. Chuck and Bearings: The standard chuck has a concentricity of 0.05mm, which makes operation more stable. 4-axis motion control: There are two modes of motion control for the XYZW axis: software automatic control and button manual control. Flat sample holder (optional): used to measure plane specimens and cubic specimens. Radial probe (optional): used for surface magnetic measurements of flat samples, cubic samples, etc.

• High precision: The measurement range of the TY2100 surface magnetic field automatic test system is 0~2000mT, the resolution is 10μT, and the accuracy is guaranteed to be within 0.5%. Its XYZ axis provides adjustable travel and positioning accuracy of ±0.02mm.
• Rotating platform: Using a rotating chuck and precision motor, it can achieve controlled rotation in the W-axis direction. The concentricity is 0.05mm, ensuring stable operation and accurate testing.
• Versatile: The 4-axis motion control supports automatic and manual modes. Optional fixtures such as flat sample holders and radial probes enhance its adaptability to a variety of sample types.
• Wide range of applications: From cylindrical magnets to motor rotors, TY2100 has a wide range of uses. Optional features extend its ability to measure surface magnetic distribution on planar and cubic samples.
• Reliable performance: Designed for a variety of environments, with an operating temperature range of 0°C to 40°C and strong moisture resistance. Its compact size ensures convenience without compromising functionality.
